Equipo de acceso óptico de 11U | 17 ranuras para tarjetas de línea (15 para servicio) | soporta 272/240 puertos GPON/10G PON
Model: C600
ZXA10 C600 is a large-capacity optical access OLT device based on the TITAN platform. It can meet the needs of ultra-high bandwidth access, 4k/8K big video and VR, fixed mobile convergence, network reconstruction, and carrier-grade QoS and security guarantees.
| Spicification of C600 | |
| SNI | 10GE, 100GE |
| UNI | PON: GPON, XG-PON, XGS-PON, XG-PON &GPON Combo PON, XGS-PON & GPON Combo PON, Any-PON; P2P: GE/FE, 10GE |
| Dimensions | 21" chassis: 486.1 mm*535 mm*288.5 mm; 19" chassis: 486.1 mm*482.6 mm*288.5 mm (H*W*D) |
| Weight | 21" empty chassis: 21 kg; 19" empty chassis: 18 kg; Full configuration 21" chassis: < 58 kg; Full configuration 19" chassis: < 52 kg |
| Work voltage | DC: -48V(+/-20%), -60V(+/-20%); -38.4V～-72V |
| Work current | DC: 60A |
| Work Temperature | -40°C ~ +65°C, min. start-up temperature is -25°C |
| Work Humidity | 5%-95% |
